Endurail Pipe Fittings

Model #
AL 33
AL 42
AL 48

Item #
BF40

Type
Base Flange

Description
Ideally used to fix down guard rail and balustrades,having sufficient dia of holes to provide good fixing either with chemical or mechanical anchor.The pipe is able to pass through the base flange / Base Flange Vertical mount.

Base Flange

Model #
AL 33
AL 42
AL 48

Item #
T 14

Type
Single Socket Tee

Description
Mostly used as the 90Deg joint between top rail and an intermediate upright on safety railing with required set screws.

Single Socket Tee

Model #
AL 33
AL 42
AL 48

Item #
E20

Type
90° Elbow

Description
A 90 Deg Elbow joint most commonly used as an end joint for the top rail of safety railing on level site.

9o deg Elbow

Model #
AL 33
AL 42
AL 48

Item #
C30

Type
Two Socket Extended Cross / Two Socket Cross

Description
Used in pair with T10 to provide a 90° joint between the middle rain and an intermediate up right on safety railing.The upright passes through the fitting.

Reducer cross

Model #
AL 33
AL 42
AL 48

Item #
E AE 22 A

Type
Adjustable Elbow

Description
A swivel fitting designed to take care of inline variable angle connection. Adjustable from 45- 200 deg.Mainly used at Stair case and Inclined rail. Swivel Male / Swivel female / Swivel Base Flange / Swivel male female assembly / Side Out let Elbow

Model #
AL 33
AL 42
AL 48

Item #
BF42

Type
Base Flange Side Mount offset

Description
Ideally used to fix guard rail form side of the structure. Base Plate having sufficient dia of holes to provide good fixing either with chemical or mechanical anchor.The side plates have slotted holes to allow for a degree of sideways movement and ease of installation.

Side Mount Base Flange - Horizontal

Model #
AL 33
AL 42
AL 48

Item #
WF 45

Type
Wall Flange

Description
Flange designed to hold rail starting /ending at wall. Can also be used to hold post in light duty application or as base.

Wall Flange
